Platform EVM Socket Pinouts
3.7 Platform EVM Socket Pinouts
Figure 3–7. Signal Conditioning Socket U1 Pinout
Signal Conditioning
VCC
VDD
GND
Right In
GND
Left In
GND
Right Out
GND
Left Out
GND
N/C
****CAUTION****
N/C
N/C
Do not insert or remove N/C
EVM boards with power
N/C
N/C
Figure 3–8. Power Amplfier Socket U2 Pinout
Audio
Power
Amps
Right In (HP)
GND
Right In (line)
GND
N/C
GND
Left In (line)
GND
Left In (HP)
applied
N/C
N/C
Right Out +
GND
Right Out –
N/C
Mode
N/C
Mute
Left Out –
GND
Left Out +
Details
